SP-ESS-1.5K-5K-E1 Wheeled home energy storage system for easy mobility, a flexible modular design,Scalable from 5 to 20 KWh
Item NO.:
SP-ESS-1.5K-5K-E1Superpack offers a complete home energy solution to suit your home conditions and lifestyle. Flexible Investment 5KWh Modular Design,Scalable from 5 to 20 KWh in off-grid scenario, The performance requirements of the market at a competitive investment cost but also save energy, increase productivity, ensure stable electricity supply and reduce energy expenses.
This specification is applied to the 5.5KWH Off-Grid Energy Storage System built in inverter + MPPT charger + Li-ion battery charger + LiFePO4 battery with BMS plus LCD display that manufactured by Superpack.
Main Features
1) 5.5KWH home energy storage system: Household self-use system.
2) Battery pack:
• LiFePO4 battery pack: 25.6V230Ah
• Max. output power: 2.5KW
3) Inverter:
• Single phase pure sine wave inverter
• AC output: 110V/60Hz Or 220V/50Hz
• Rated output Max power: 2000W
4) MPPT charging controller:
• Max. voltage of PV: 100V
• Max. power of PV: 1100W
• Charging method: CC/CV
• Max. charging voltage: 29.2V (adjustable)
• Max. charging current: 40A
5) AC charger:
• AC input: 110V/60Hz OR 220V/50Hz is available)
• Max. output power: 600W
• Charging method: CC/CV
• Max. charging voltage: 29.2V (adjustable)
• Max. charging current: 20A
6) Solar panel
• Single panel: 400W
• System assembling: 1PCS, 400W Or 2PCS, 400W OR 3PCS, 400W
Item
Parameters
Remark
Battery Pack
Chemistry
Lithium Iron
Phosphate (LiFePO4)
Cell
Brand
BYD Brand
Nominal
Capacity
230AH
RatedBatteryVoltage
25.6V
Max.
Charging Voltage
29.2V
Standard
Charge
20A constant
current (CC) charge to 29.2V,then constant voltage (CV) 29.2V charge till
charge current decline to ≤0.05C at 25℃
Max.
Charging Current
66A
Standard Discharge
Constant current 0.2C cut-off voltage 20.0V
25℃
Max. Continuous Discharge Current
100A
Max. Output Power
2.5KW
Charge Cut-off Voltage
≤30.4V
(3.8V/cell)
Discharge Cut-off Voltage
≥ 20.0V
(2.5V/cell)
Cycle life
1200cycles
standard charge/discharge
ChargingTemperatureRange
≤ 30A at
0~10℃
≤ 66A at
0~50℃
Discharge TemperatureRange
≤ 20A at
-10~0℃
≤ 50A at
0~10℃
≤ 100A at
10~55℃
Relative Humidity
5~95%
Weight
60kgs
Dimensions
W425.0±3*D160.0±3*H557.0±3mm
Storage TemperatureRange
SOC 30~50% ≤3
months:-5~35℃
Item |
Parameters |
|
Inverter |
||
Model |
SP-1500W (Single phase pure sine wave) |
|
Output Voltage /Frequency |
110Vac/60Hz OR 220V/50Hz |
|
Rated Output Power |
1500W |
|
Peak Output Power |
3000W |
|
DC Input Voltage Range |
19.0~30.0V |
|
Efficiency |
≥ 90.0% |
|
Power Factor |
95% |
|
Working Temperature Range |
-20~60℃ |
|
Overload Protection |
Yes |
|
Over-temperature Protection |
Yes |
|
Noise |
60dB(A) |
|
Cooling Method |
Electric Fan |
|
Relative Humidity |
≤95% |
|
MPPT charging controller |
||
Model |
24V40A |
|
PV Input Voltage Range |
30~100V |
|
Max. PV Input Power |
1100W |
|
Max. Charging Voltage |
29.2V |
|
Max. Charging Current |
40A |
|
Efficiency |
98% |
|
Static Self-consumption |
≤10Ma |
|
Working Temperature Range |
-20~60℃ |
|
Relative Humidity |
≤95% |
|
Over Temperature Protection |
Yes |
|
Reverse Connection Protection |
Yes |
|
Start Charging Voltage |
16V |
|
Charging Cut-off |
MPPT turn off charging automatically when fully charged |
Item |
Parameters |
Remark |
Li-ion Battery Charger |
|
|
Model |
SP-600W (Li-ion battery charger) |
|
AC Input |
110Vac/60Hz (220V/50Hz is available) |
|
Charging Method |
CC/CV |
|
Max. Output Voltage |
29.2V |
|
Constant Charging Current |
20A |
|
Max. Output Power |
600W |
|
Efficiency |
≥ 90.0% |
|
Reverse Connection Protection |
Yes |
|
Over-temperature Protection |
Yes |
|
Charging Cut-off |
Charging current less than 1A |
|
Charger Start Charging Voltage |
16V |
|
Cooling Method |
Electric Fan |
|
Working Temperature Range |
-20~60℃ |
|
Relative Humidity |
≤95% |
|
PV Panel |
||
Model |
SW400MR |
|
Max. Power |
400W (single panel) |
|
Max. Power Voltage |
37.62V |
|
Max. Power Current |
10.64A |
|
Open Circuit Voltage |
45.52V |
|
Short Circuit Current |
11.27A |
|
Efficiency |
20.12% |
|
Working Temperature Range |
-40~85℃ |
|
Max. System Voltage |
1000Vdc |
|
Max. Series Fuse Rating |
15A |
|
Power Tolerance |
±5% |
|
STC Condition |
1000W/m2, 1.5AM and 25℃ cell temperature |
Item |
Parameters |
Remark |
|
The System |
|||
Model |
5.5KWH Home Energy Storage System |
|
|
Built-in Main Components |
Inverter + MPPT charger + Li-ion battery charger + LiFePO4 battery with Smart BMS plus LCD display |
||
Input |
L-ion battery charger for AC input |
29.2V/20A for 12hours (approx) |
|
MPPT charger for PV input |
29.2V/40A for 6hours (approx) |
||
PV Panel Assembling |
2pcs 400W PV panels connecting in parallel |
Total 800W |
|
Output |
2000W single phase pure sine wave |
||
110V/60Hz Or 220/50Hz |
|||
Efficiency |
90% |
||
Power Factor |
0.95 |
||
BMS |
Monitoring battery voltage, current, temperature to protect from overcharge, over discharge, over current, short circuit, over heat, under temperature and learning SoC. |
||
LCD Display |
Display battery operation status, such as SoC, voltage, current, temperature, or error alarming |
||
System Cooling |
Electric Fan (Nature air) |
||
Working TemperatureRange |
-0~40℃ in door (is recommended) |
||
Relative Humidity |
≤95% |
||
System Connection |
|||
PV input + |
Female connector 20A,PV Cable conductor cross-section1.5mm2 |
|
|
PV input - |
Male connector 20A, PV Cable conductor cross-section1.5mm2 |
|
|
MPPT on/off |
Switch on or off MPPT charging |
Item |
Parameters |
|
The System |
||
System Connection |
Can be customized |
|
Lithium-ion Battery Charger Connector |
AC Input 110V/60Hz |
|
Female Connector |
||
Charger ON/OFF |
Switch ON or OFF AC charging |
|
Output |
AC Output 110V/60Hz |
|
2*Female Connector |
||
Inverter ON/OFF |
Switch ON or OFF AC output |
|
Efficiency |
90% |
|
Power Factor |
0.95 |
|
Overload Protection |
≥105% rated power of inverter |
|
Over Temperature Protection |
≥ 70℃ |
|
Short circuit protection |
Yes |
|
Short circuit protection release |
Remove external load Or Switch OFF |
|
Weight (kg) |
85 |
|
Dimension |
W500*D300*H790mm |
|
Case Material |
Metal sheet |
|
Enclosure Protection |
IP20 |
|
Certification |
IEC62619, IEC62109, CE61000,UN38.3 |
